Google Android Application Development Utilizing Background Processes

Android is one of the fastest growing operating systems and software stacks for smartphones. OS smartphones ranked second among all smartphone OS handsets sold in the U.S. in the first quarter of 2010. Dell, HTC, Motorola and Samsung are some of the manufacturers using this operating system.

Google opened the source code under an Apache License and now the Android SDK allows developers to write managed code in the Java language, controlling the device via Google-developed Java libraries. The SDK includes a comprehensive set of development tools, such as a debugger, libraries, a handset emulator, documentation, sample code and tutorials.

Applications that run in the background are supported in Android in contrast to iPhone. All of these facts stimulate me to research this interesting technology. I decided to make an application running in the background and receiving the GPS location. The main goal was to inform the user not to write or read text messages while he or she is driving.

It is pretty easy to develop an Android application, especially if you are using Eclipse. You can download the latest version of the Android SDK from the official site. There are a lot of tutorials explaining how to install and use the SDK in Eclipse, if you are a beginner you can take a look at the developer’s guide.

Utilizing the GPS Module

As you may know smartphones have a gps module which provides the current location. This feature is used in many applications. To implement it you have to modify the AndroidManifest.xml, this is the main configuration file.

With these permissions you tell to the application that the GPS module will be used and the application is given access to it.

The Activity Class

There is one very important class in an application’s overall lifecycle – the Activity class. It takes care of creating a window for you in which you can place your UI. But this activity is not enough to create a background process. It should be used in conjunction with another object from the ContextWrapper to achieve the behavior of an application component that runs in the background and doesn’t interact with the user. This functionality is given up by the Service class. Both the activity and the service should be declared in the android manifest file.

My idea is to create a main activity class and in the onCreate() method call the service. But when something is started, there needs to be a way to stop it. The best place to stop the service is in the onDestroy() method of the main activity. These two methods are overridden because the main activity has to extend the Activity.java class. They look like:

This is how the activity class looks. The service class will manipulate the GPS module data. It will get the location in a time interval, get the speed or calculate it if it is not available and finally if the speed is more than 10km/h it will inform the user not to use the phone’s features while driving in order to avoid accidents.

The Service Class

As the main activity extends Activity.java class, the service should extend the Service.java class. The service is started in the overridden method onCreate() of the class.

First a timer object is needed which will take care of calling the service. To schedule the timer you have to prepare a TimerTask instance, which calls your business logic. In the example it is called the getUpdateLocation() method, its functionality will be explained later in this post. The timer is scheduled with the timer task and the specified time interval passed as a constant.

Lets take a look at the getUpdateLocation() method. As the title says, the method gets the location from the LocationManager.java class. The locations are separated by providers, so they are filtered with a criteria. Some GPS providers send the speed of the device. But if the speed is not received, it can easily be calculated as a quotient of the distance between the current and previous location with the subtraction of the two times.

The user will be informed with a warning message, if the calculated speed is more than a specified value. This is the business logic, but there is one other thing to take care of – the timer. The timer is started in the onCreate() method of the service class. It will be stopped in the onDestroy() method of the service class. The cancel() method will then be called in order to cancel the timer and remove any scheduled tasks.

The completed application will run in the background and inform the user with a message that his or her speed is more than 2.78 meters per second.

speed1

9 Easy Ways to Speed Up Your Website’s Load Time

Google recently announced that they began factoring in web site load time into their search engine ranking algorithm. This has brought the importance of a fast load time front and center even though “fewer than 1% of search queries will change as a result” of this update. MentorMate.com likely was not impacted very significantly from this change to Google’s ranking algorithm; however, we still decided to optimize our site’s load time. We did this because Google showed that “delays of under a half-second impact business metrics.” It’s better to be safe than sorry, and besides, it’s not that difficult to optimize your site. We recommend you do the same with your web site, here are nine easy ways to do just that:

1. Place scripts near closing body tag

Scripts block parallel downloads. While a script is downloading, the browser will wait until it finishes before downloading anything else. This is why it is recommended that you get everything else out of the way before having your users download scripts.

2. Remove any broken links/references

Simply enter your web page URL in Pingdom’s Full Page Test Tool. This tool will color-code any broken links/references in red so you can easily identify them.

3. Specify image dimensions

When image dimensions are not specified in the HTML and/or CSS of a web page, the web server must spend resources calculating these dimensions. It’s particularly important to specify the dimensions of images being used in conjunction with heavy Javascript image-manipulation libraries.

4. Localize external file references to minimize DNS requests

This is another spot in which Pingdom’s Full Page Test Tool comes in handy. Enter your URL and look for any file references to external domains. If possible, copy these files onto your own domain and link to them locally to minimize DNS requests.

5. Minimize slow-loading libraries and external widgets

Libraries and external widgets need to be chosen carefully. Sometimes it’s worth sacrificing load time for particularly engaging/useful libraries and/or widgets; however, sometimes you can live without the library and/or widget. For example, on MentorMate.com we felt it was worth sacrificing Sexybuttons for better load time, but sacrificing load time for Shadowbox. External widgets can be particularly bad for a site’s load time because of their reliance on external servers.

6. Compress your files using gzip

These days, gzip comes pre-installed on most web servers. You can check to see if gzip is running your server quite easily using Google’s Firebug “Speed Test” extension. Open Firefox, visit the web site you’d like to optimize, and open Firebug. From there, click “Analyze Performance” and select the “Resources” tab. Then you can expand any file to view details. If gzip is installed and compressing the element you are viewing, you will see what is highlighted in red in the following screenshot:

gzip

7. Merge Javascript and CSS files or use Minify

Depending on the complexity of your site, it can be quite time consuming to merge all CSS into one file. The same goes for Javascript. This is why Minify was developed.  Minify “combines multiple CSS or Javascript files, removes unnecessary whitespace and comments, and serves them with gzip encoding and optimal client-side cache headers.” Then you simply need to install it on your site, select the files you want it to serve together, change some references in your header, and you’re good to go. This will minimize your site’s load time by further helping to reduce HTTP requests.

8. Load cross-browser compatibility hacks only for necessary browsers

For instance, we use the IE PNG FIX for IE6 PNG transparency compatibility. This script adds an extra second to web site load time. For this reason, we only load the script if the visitor is running IE6 by applying an IE6-specific stylesheet which references the IE PNG FIX. This way the extra load time will only impact IE6 visitors.

We simply added the following line of code to our header:

9. Use CSS sprites to minimize HTTP Requests

A CSS sprite is the combination of multiple images into one. Then CSS is used to reference different aspects of the image where needed. This reduces load time by minimizing all of these images into only one  HTTP request. CSS Tricks has a good example of CSS sprites.

charts painted1

JFreeChart Bar Chart Tutorial for Dynamic Java Web Applications

JFreeChart is an open-source Java based library which allows the creation of complex charts in a simple way.

Supported chart types include:

  • X-Y charts (line, spline and scatter);
  • Pie charts;
  • Gantt charts;
  • Bar charts (horizontal and vertical, stacked and independent);
  • Single valued (thermometer, compass, speedometer).

I am going to explain how to use the chart library and how to create a bar chart with a custom color. To create a chart with JFreeChart library, first you have to make a Dataset object. The chart is generated from this data collection. Next you have to instate the class DefaultCategoryDataset, which is passed to the chart object. In the code below as a data source is used ArrayList, which may come from data base.

The next step is to do an object from chart type. The library uses a class named JFreeChart to display the chart. This chart object is an instance, which comes from the method createBarChart ofthe static class ChartFactory. The method takes as a parameter the formed collection (dataset). There are many properties, which you can pass to the constructor, such as labels, orientation, etc. It is possible to change colors, size, scale and many other characteristics.

You have ready object now and the next step is to send the chart to the web page. For this purpose, the library includes a class named ChartUtilities that provides several methods for saving charts to files or writing them out to streams in JPEG or PNG format. The methods from this class can be used for creating JPEG images for static web pages. The goal, however, is not to save the chart in a hard drive; the goal is to pass the graphic to the application. To do that, you can use the servlet technology and display the dynamic data stream in the jsp pages.

Consequently the next step is to generate BufferedImage from your chart object and to transfer this stream through the session. You should also write the image in the http response writer.

Finally you should write the servlet. This is a Java object, which dynamically answers requests and built response to the client. Each servlet has two main methods – doGet(HttpServletRequest request, HttpServletResponse response) and doPost(HttpServletRequest request, HttpServletResponse response). You need to get the chart stream from the session in the servlet. The image is set to an attribute named chartImage in the session. You have to get http session instance from the request and then to retrieve the previously set attribute.

Want to learn more about our custom development capabilities? Talk with us.

51262107 29dc 47d3 8fdd ce19890d5e09
parser1

iPhone Application Development XML Parser/Parsing Libraries

Existing APIs for XML processing fall into two categories:

  • SAX (Simple API for XML) is a serial access parser API for XML. It provides a mechanism for reading data from an XML document. The quantity of memory that a SAX parser must use in order to function is typically much smaller than that of a DOM parser. Unlike DOM, there is no formal specification for SAX.
  • The Document Object Model (DOM) is a cross-platform and language-independent convention for representing and interacting with objects in HTML, XHTML and XML documents. It represents a tree structure based API. The Dom parser implements the DOM API and it creates a DOM tree in memory for a XML document. Because DOM supports navigation in any direction (e.g., parent and previous sibling) and allows for arbitrary modifications, an implementation must at least buffer the document that has been read so far (or some parsed form of it).

Cocoa offers a “complete” XML parser with the NSXML family of classes.

  • NSXMLParser is a SAX parser, meaning that it traverses the XML tree and informs a delegate of events as they happen. This is an event-driven parser, which calls methods on a delegate to handle “events” as it parses through the XML.
  • NSXMLDocument provides tree parser functionality. An instance of NSXMLDocument represents an XML document as internalized into a logical tree structure. This tree-based parser is fairly sophisticated but it is not included in Cocoa-Touch.

In the spirit of small and simple, iPhone developers have the NSXMLParser class to use. Because NSXMLParser only generates messages for a delegate, and doesn’t store data about the XML tree, it requires less memory and is better for accessing small pieces of data or parsing large XML documents. The basic operation of the NSXMLParser class will not be covered here. This is well documented in the Apple Programming Guide.

For devices like iPhone where memory usage is critical, using tree parser is not recommended. I guess that is why Apple doesn’t provide NSXMLDocument on iPhone/iPod touch. However, the model of event parsing may not be acceptable by your code. NSXMLParser is probably adequate, but it is not going to handle all your XML parsing needs. The biggest problem with this type of streaming parser is that you lose the structure of your data; your call-backs do not provide any context or hierarchy. Because of the above mentioned or by some other reason like often changing XML format [1] you may need to use something like DOM model implementation.

Available Libraries (DOM model implementations) for iPhone

Which parser (DOM or SAX) should you use?

Well, if you’re going to need to parse very large XML documents, then you should probably consider NSXMLParser. What “very large” means depends a lot on the available memory you have to work with? The model of iPhone and the memory already in use by your app may prevent you from being able to use DOM model.

While DOM model usage may seem easier, NSXMLParser really excels in situations where you’re loading in many instances of the same kind of data, such as an address book or twitter feed. However, if memory is not an issue, I would recommend DOM model. It makes it easy to access the data you want and also allows you to manipulate the tree.

References

  1. Arash Payan(Salman),APXML: NSXMLDocument ’substitute’ for iPhone/iPod Touch – Arash Payan,Sep 27th, 2009
  2. jongampark, Tree XML parser for iPhone, 2009
